Passing SMB to LXC on Proxmox

I’ve started to think differently about mounting my SMB shares inside my LXC containers. The main benefit has always been portability. Migrating an LXC between hosts in a cluster was easy because the mount was configured in the LXC itself.

There are some serious drawbacks to this approach though, mainly security. Having to run the LXC as root. Also, remounting if there is a connectivity issue with the SMB share. You can’t use systemd automount without opening permissions up even further, which again, security. This finally got to me, so I swapped everything to mount on my proxmox hosts instead. Here’s how I did it.

Automounting

One major benefit to using the host is being able to use the mount and automount units for systemd. This way any issue with my NAS restarting, or a drop in connectivity, the automount will automatically reconnect. To configure this, I needed to set up the unit files on the host. I keep these files in a folder in the root home called systemd-mount so lets start there.

cd /root
mkdir systemd-mount
chmod 700 systemd-mount
cd systemd-mount

The idea of this folder is to keep everything in an easy to remember place. Proxmox uses root by default, so there’s no permissions issue either.

Folder Structure

Next I want to create a folder to keep each share separate. I like to use the naming convention of [NAS host]-[share name]-[share user]. For this example I’m going to create filehost-documents-proxmox.

mkdir filehost-documents-proxmox
chmod 700 filehost-documents-proxmox
cd filehost-documents-proxmox

Now I can create my unit files, starting with the mount unit. The naming convention for mount unit files is specific and must follow the folder path. So a mount unit that creates a mount at /mnt/filehost/documents/ would need to be named mnt-filehost-documents.mount. Same for automount. I will also create a credentials file.

touch mnt-filehost-documents.mount
touch mnt-filehost-documents.automount
touch documents-proxmox-credentials
chmod 700 *

Mount Unit

# mnt-filehost-documents.mount
[Unit]
Description=samba mount for //filehost.internal/documents for the proxmox user
Requires=systemd-networkd.service
After=network-online.target
Wants=network-online.target

[Mount]
What=//filehost.internal/documents
Where=/mnt/filehost/documents
Options=vers=3.0,credentials=/root/systemd-mount/filehost-documents-proxmox/documents-proxmox-credentials,iocharset=utf8,rw,x-systemd.automount,uid=101000,gid=101000
Type=cifs
TimeoutSec=30

[Install]
WantedBy=multi-user.target

Automount Unit

# mnt-filehost-documents.automount
[Unit]
Description=Automount for mnt-filehost-documents

[Automount]
Where=/mnt/filehost/documents
TimeoutIdleSec=0

[Install]
WantedBy=multi-user.target

Credentials

# documents-proxmox-credentials
username=documents-proxmox
password=your_share_password

Symlink’ing into systemd

Now that the units are created, I have to link them into /etc/systemd/system. I can use systemd link to create the symlinks. Remember, the link requires the absolute path and will fail with a relative one.

systemctl link /root/systemd-mount/filehost-documents-paperless/mnt-filehost-documents.mount
systemctl link /root/systemd-mount/filehost-documents-paperless/mnt-filehost-documents.automount

Once linked, I can verify with ls -la /etc/systemd/system/mnt*. I see my new units symlink’ed into the correct place, and now I can reload systemd and enable the automount service.

systemctl daemon-reload
systemctl enable --now mnt-filehost-documents.automount
systemctl status mnt-filehost-documents.automount
systemctl status mnt-filehost-documents.mount

To verify the share is mounted I look to see if my files are in the folder i specified in the mount unit.

ls -la /mnt/filehost/documents

Adding the Share in LXC

Now I can add the share to my LXC container. In Proxmox, these are called mount points. Navigate to the LXC file and add the mount point to the configuration.

cd /etc/pve/lxc
ls -la

  hostname: paperless
  arch: amd64
  cores: 4
  memory: 2048
  tags: debian13;samba;

  ---

  unprivileged: 1
  features: nesting=1

+ mp0: /mnt/filehost/documents,mp=/mnt/documents,replicate=0

The first path configures the host mount folder. The second is where that folder will appear in the LXC. replicate=0 tells proxmox not to back up the share. Now I should be able to start my LXC and navigate to the mount point from within.

ls /mnt/documents

Happy Homelabbing!
